Wind power company SeaTwirl AB conducted various tests in November at SSPA (Swedish State Shipbuilding Experimental Tank).
At the end of November, SeaTwirl conducted several tests at SSPA, which is located at the Chalmers University of Technology’s Johanneberg campus, in Gothenburg. Tests were conducted on the wind turbine’s floater in the SSPA’s Maritime Dynamics Laboratory (MDL), which simulates maritime environments with waves and currents. The model tested had a scale corresponding to 1:40 of SeaTwirl S2x, and the tests were conducted to confirm the Company’s own simulations of anchoring forces, the Magnus effect and the structure’s movements. The tests were conducted in combinations of currents, waves and rotational speeds to identify the impact from all input data, dependently and independently of each other.
A key parameter for hydrodynamic analyses is the heave period, which is why a stationary test was carried out. The test was conducted to validate the heave period of the structure. The method involved lifting the model slightly and subsequently allowing it to fall, and then measuring the heave periods until the model was stationary again. The result was a longer period than assumed in the simulations, which is highly positive because it reduces the risk of large heave motions.
Rotating on the floater as done by SeaTwirl S2x is relatively unique and gives rise to the Magnus effect when water surges onto the structure. The Magnus effect results in a force that is perpendicular to the surge direction on a rotating cylinder. A key feature of the tests was to investigate how the Magnus effect is impacted by rotational speeds, waves and currents for SeaTwirl S2x. The tests were first conducted without waves with a current, which was simulated by dragging the structure in the tank. When these tests were complete, the same tests were conducted with varying wave heights and wave intervals.
The results of these tests were manifold, but one initial significant result is that it is evident that the approach adopted by the Company is close to reality, which is very positive. In addition, the result will be used to refine the Company’s simulation models for future simulations.
Measurements of the forces on the anchor cable were taken in all trials to be used as validation of the simulation models. The Company uses several hydrodynamic simulation tools and data from these tests are extremely valuable in ensuring that all models provide satisfactory, accurate results.
“The tank tests are an important milestone for the project and for the technical solution selected by the company. Through this collaboration with SSPA, we have gained much more than we first expected from the tests. It has been instructive and it is fantastic that the results show that we have a conservative approach in the simulations of S2x. We are quite simply very satisfied.” Jonas Boström, CTO SeaTwirl.
